Frameless Glass Partitions

A best-seller for commercial and residential spaces, a true
modern frameless glass solution to match any interior.

Get a free estimate With quick turnaround
  • Sliding doors
  • Swing doors

Frameless slidingglass doors

Top-hung frameless sliding partition with polished edges for those who seek lightness and simplicity for their minimalistic interior.

  • Multiple glass finishing options include clear, low iron, bronze, gray, and frosted.
  • Glass panels are available in custom widths and heights, with 11 feet as the maximum height for monolithic tempered glass panels.
  • Tempered glass thickness may be either ⅜’’ or ½’’. Smaller thickness reduces the weight, but panels are still really durable.
Get a free estimate With quick turnaround

Key Features

Tap to view more information

Glass type

Monolithic tempered glass up to 1/2’’ thick, the finish of your choice

Bottom guide

½’’ high bottom guide holds the sliding door in place

Handles

Door handle of your choice

Integrated top channel

Top channel for the fixed panel is concealed in the sliding top track minimizing the gap between the panels to ½’’

Rollers

Ball bearing rollers with an anti-shock braking system

System configuration

One sliding door

A single sliding door moving to the left or to the right

One sliding door + one fixed panel

A single sliding door with a fixed sidelight moving to the left or to the right

Two sliding doors

Double sliding doors moving in opposite directions

Two sliding doors + two fixed panels

Double sliding doors moving in opposite directions with fixed sidelights on each side

The new soft-closing technology

The new soft-closing technology from CRYSTALIA which combines two nitrogen gas pistons and one oil-filled piston all within the same unit.

The new soft-closing technology

The new soft-closing technology from CRYSTALIA which combines two nitrogen gas pistons and one oil-filled piston all within the same unit.

Features:

  1. The closing action is PROGRESSIVE and slows down as the door approaches the fully closed position
  2. Anti break feature on the trigger
  3. Ensures safe braking and prevents bouncing of the door
  4. Ensures the door is braked SAFELY
  5. Ensures the door is held firmly in the closed position
  6. Combines an aesthetically pleasing action with safe soft closing for doors up to 242 lbs
Profiles
Track A
2-5/16” x 2-3/8”
Bottom Channel
5/8” x 3/8”
Profiles Frame
1-1/8″ х 3/8″
Specifications
Gap A
Glass 3/8″ > Gap 3/4″
Glass 1/2″ > Gap 5/8″
Gap B
7/16”
Glass
3/8”-1/2”
MAX 242 lbs
